Spesifikasi Honda CB125R 2024
Total length x width x height 2025×820×1055mm
Wheelbase 1345mm
Minimum ground clearance 140mm
Seat height 816mm
Vehicle weight 130kg
Engine type Water-cooled 4-stroke DOHC 4-valve single cylinder
Total displacement 124.9cc
Bore x stroke 57.3×48.4mm
Compression ratio 11.3:1
Maximum output 14 HP/10000rpm
Maximum torque 11,6Nm/8000rpm
Fuel tank capacity 10.1L
Transmission type 6 speed return
Caster angle 24.2°
Trail amount 90.2mm
Brake type (front/rear) Φ296 disc/Φ220mm disc
Tire size (front/rear) 110/70R17M/C 54H・150/60R17M/C 66H
Fuel consumption rate WMTC mode value 45.5km
